18
Chatper 2 - Connections
GFR-700 Owner’s Manual
Digital Audio Connections
The GFR-700 features six digital audio inputs—three
coaxial and three optical—to receive multi-channel
bitstreams from your DVD player or other digital au-
dio source component.
Connecting Digital Audio Components
1 Choose an available digital audio input.
2 Connect digital audio cable(s).
• Using a digital coaxial audio cable, connect
the coaxial output on your source device to
the corresponding coaxial input on the GFR-
700.
• Alternatively, use an optical (Toslink) cable
to connect the optical output on your source
device to the corresponding optical input on
the GFR-700.
3 Associate the digital audio input with a Video in
-
put.
• See page 33 to associate the digital audio
input with the Video 1-4 or CD input.
Notes:
• The digital audio inputs are
assignable to the Video 1-4 or
CD inputs; see page 33.
Coaxial
Digital Audio
Inputs 1~3
Optical
Digital Audio
Inputs 1~3
To Next Page
