Safewatch Pro 3000 Installation Instructions
3-6
Interactive Mode Programming (
∗
56, *57,
∗
58,
∗
79,
∗
80,
∗
81,
∗
82)
Entering Interactive Mode
Press [
∗
] + [Interactive Mode No.] (for example,
∗
56) while in Program Mode.
The Custom English display touchpad will display the first of a series of
prompts requesting entries.
After making the appropriate entry, press the [∗] key to accept the entry and
continue to the next prompt.
Loading Factory Defaults/Initializing for Download
To Load Default Entries
Press ∗97 while in Program Mode. This resets all data fields to the ADT
default values shown in the boxes in the Program Form. Use
∗
97 only if you
wish to return to the original factory-programmed defaults.
To Initialize Download ID
Press ∗96 while in Program Mode. This initializes the system for
downloading and resets all the subscriber account numbers and CSID.
Do not press
✱
97 to load defaults if any programming has been done previously—data already
programmed into the system will be changed!
Exiting the Programming Mode
Prevent installer code reentry
Press ∗98. Exits Programming Mode and prevents re-entry by:
Installer Code + [8] + [0] + [0]. To enter the programming mode if
∗
98 was
used to exit, you must first power the system down. Then power up again,
and press [∗] and [#] at the same time, within 50 seconds of powering up.
Allow installer code reentry
Press ∗99. Exits Programming Mode and allows re-entry by:
Installer Code + [ 8] + [0] + [0] or by: Pressing [∗] and [#] at the same time,
within 50 seconds of power-up.
Table of Device Addresses
Address Report
†
Device Programmed by…
00 100 RF Receiver *56 zone programming: input device type entry
03 103 Long Range Radio automatic if output to long range radio field *29 enabled
04 104 4286 Voice Module automatic if phone module access code field *28 enabled
Zone Expanders (4219/4229): *56 zone programming: input device type entry, then:
07 107 module 1 zones 09 - 16
•
automatically assigned if zone number 9-16 entered as AW type
08 108 module 2 zones 17 - 24
•
automatically assigned if zone no. 17-24 entered as AW type
09 109 module 3 zones 25 - 32
•
automatically assigned if zone no. 25-32 entered as AW type
10 110 module 4 zones 33 - 40
•
automatically assigned if zone no. 33-40 entered as AW type
11 111 module 5 zones 41 - 48
•
automatically assigned if zone no. 41-48 entered as AW type
Relay Modules (4204): *79 output device programming: device address prompt:
12 112 module 1
•
entered at device address prompt
13 113 module 2
•
entered at device address prompt
14 114 module 3
•
entered at device address prompt
15 115 module 4
•
entered at device address prompt
Touchpads: data filed programming as listed below:
16 n/a touchpad 1
•
always enabled for partition 1, all sounds enabled.
17 n/a touchpad 2
•
data field *190
18 n/a touchpad 3
•
data field *191
19 n/a touchpad 4
•
data field *192
20 n/a touchpad 5
•
data field *193
21 n/a touchpad 6
•
data field *194
22 n/a touchpad 7
•
data field *195
23 n/a touchpad 8
•
data field *196
28 n/a 5800TM Module automatic
† Addressable devices are identified by “1” plus the device address when reporting. Use zone 91 to
enable/disable addressable device reporting (default = reports enabled). See field *199 for
addressable device (ECP) 3-digit/2-digit identification touchpad display options.
