Safewatch Pro 3000 Installation Instructions
4-12
Touchpad Programming Fields
FIELD TITLE and DATA ENTRIES EXPLANATION
*190
Touchpad Device Address 17
1st Digit – Partition Assignment:
0 = touchpad disabled
1 = partition 1
2 = partition 2
3 = common
2nd Digit – Sound Option:
0 = no suppression
1 = suppress arm/disarm and E/E/ beeps
2 = suppress chime beeps only
3 = suppress arm/disarm, E/E/ beeps and
chime beeps
Touchpad 2
First digit: Enter the partition in which the touchpad is located.
Second digit: Enter the desired sound option for this touchpad.
NOTE: Address 16 is reserved for touchpad 1, which is automatically
set to partitioin 1 with all sounds enabled.
*191
Touchpad Device Address 18
See field *190 for entries.
Touchpad 3
First digit: Enter the partition in which the touchpad is located.
Second digit: Enter the desired sound option for this touchpad.
*192
Touchpad Device Address 19
See field *190 for entries.
Touchpad 4
First digit: Enter the partition in which the touchpad is located.
Second digit: Enter the desired sound option for this touchpad.
*193
Touchpad Device Address 20
See field *190 for entries.
Touchpad 5
First digit: Enter the partition in which the touchpad is located.
Second digit: Enter the desired sound option for this touchpad.
*194
Touchpad Device Address 21
See field *190 for entries.
Touchpad 6
First digit: Enter the partition in which the touchpad is located.
Second digit: Enter the desired sound option for this touchpad.
*195
Touchpad Device Address 22
See field *190 for entries.
Touchpad 7
First digit: Enter the partition in which the touchpad is located.
Second digit: Enter the desired sound option for this touchpad.
*196
Touchpad Device Address 23
See field *190 for entries.
Touchpad 8
First digit: Enter the partition in which the touchpad is located.
Second digit: Enter the desired sound option for this touchpad.
*197
Exit Time Display Interval
0 = no display
1-5 = seconds between display updates
If enabled, touchpads display the exit time remaining after arming
the system, with display updates at the interval selected (i.e. if the
exit delay is 30 seconds and “2” is selected in this field, the touchpad
display refreshes every 2 seconds, displaying 30, 28, 26, 24, etc.).
An interval greater than “1” may be necessary for some older
touchpads to allow users time to enter key presses between display
updates.
*198
Display Partition Number
0 = no
1 = yes
If selected, the partition number is displayed in the upper-left corner
of the display. This is useful when using the GOTO partition
function.
*199
ECP Fail Display
0 = 3-digt display (“1” + device address)
1 = 2-digit fixed-display as “91”
Select “0” if using Custom English touchpads and/or 3-digit English
Display touchpads. ECP faults will display “1” plus the device
address (00-30) of device causing the fault (e.g., faults on device 07
display as “107”).
Select “1” if using 2-digit English Display touchpads (e.g., certain
6128 series touchpads). If selected, ECP faults for all devices will
display as “91” on 2-digit displays, and “191” on 3-digit or Custom
English touchpads.
