4-11
Configurable Zone Type Charts
DIGIT 1 DIGIT 2
Response when system disarmed and zone is:
Intact EOL
RF zone normal
Open
RF zone N/A
Shorted
RF zn off-normal
Auto
Restore Vent Zone
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = normal
4 = alarm
8 = trouble
12 = fault
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = no
4 = yes
0 = no
8 = yes
Digit 1 = EOL + Open Digit 2 = Short + auto restore + vent zone
DIGIT 3 DIGIT 4
Response when armed STAY and zone is:
Intact EOL
RF zone normal
Open
RF zone N/A
Shorted
RF zn off-normal
Byp. when
disarmed
Byp. when
armed
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = normal
4 = alarm
8 = trouble
12 = fault
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = no
4 = yes
0 = no
8 = yes
Digit 3 = EOL + Open Digit 4 = Short + byp. disarmed + byp. armed
DIGIT 5 DIGIT 6
Response when armed AWAY and zone is:
Intact EOL
RF zone normal
Open
RF zone N/A
Short
RF zn off-normal
Dial Delay
(see field *50)
Fault Delay
(see field *53)
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = normal
4 = alarm
8 = trouble
12 = fault
0 = normal
1 = alarm
2 = trouble
3 = fault
0 = no
4 = use delay
0 = no
8 = use delay
see note 1
Digit 5 = EOL + Open Digit 6 = Short + dial delay + fault delay
DIGIT 7 DIGIT 8
Display Faults Power Reset/
Verification
Use Entry
Delay 1/2
Use Exit
Delay
Respond as
Interior Type
0 = always
1 = when
disarmed
3 = never
0 = no
4 = power reset
after fault
12 = verification
(see zone
type 16)
0 = no
1 = delay 1
2 = delay 2
0 = no
4 = use exit
delay
0 = no
8 = yes ()
see note 2
Digit 7 = fault display + power
reset/verification
Digit 8 = entry delay 1/entry delay 2 + exit delay +
interior zone type
DIGIT 9 DIGIT 10
Alarm Sounds Use Bell
Timeout
Respond as
Fire Zone
Trouble
Sounds
Chime when Chime
Mode On
0 = none
1 = steady
touchpad
2 = steady bell
and
touchpad
3 = pulsing bell
and
touchpad
0 = no
4 = yes
see fields *32,
*33
0 = no
8 = yes
see zone type
09; see note 4
0 = none
1 = periodic
beep
2 = trouble
beeps
0 = no
4 = yes
Digit 9 = alarm sounds + bell timeout + fire zone Digit 10 = trouble sounds + chime
OPEN SHORTEDINTACT
EOL
ADT3000-018-V0
Zone Conditions Represented
in Digits 1-6
Configurable Zone Type Notes
1. Do not use the “fault delay” option
with a configurable zone type if it
is set for an entry or exit delay,
otherwise unpredictable results
may occur.
2. To create an interior type zone,
select “respond as interior zone
type” (Digit 8, interior type = yes),
and set zone response to “fault” in
digits 3-4 to ensure fault displays;
do not set as “normal,” “alarm,” or
“trouble.”
3. Do not set fire zones to respond as
a “fault” (digits 1-6), otherwise
faults will not display unless the
[
∗
] key is pressed.
4. 4219/4229 modules must use
EOLRs or unpredictable results
may occur.
5. RF ZONE NOTE: The “open”
option in digits 1, 3, and 5 is not
applicable for RF zones. Use the
“intact EOL” option for normal RF
zone conditions and “shorted” for
off-normal RF zone conditions.
