Safewatch Pro 3000 Installation Instructions
3-2
Touchpads
Touchpads are identified by predefined addresses as follows:
Address Touchpad Program Field
16 touchpad 1*
•
always enabled for partition 1, all sounds enabled.
17 touchpad 2
•
data field *190
18 touchpad 3
•
data field *191
19 touchpad 4
•
data field *192
20 touchpad 5
•
data field *193
21 touchpad 6
•
data field *194
22 touchpad 7
•
data field *195
23 touchpad 8
•
data field *196
To enable touchpads:
1. Set desired address at touchpad (refer to touchpad’s instructions for setting the address).
2. Use data field program mode to enable touchpad addresses, assign a partition, enable sound
options in fields *190-*196 as shown in the table above.
3. If desired, use data field *198 to turn on the display of the partition number.
4. Set the following touchpad-related data fields as required by the installation:
*21 Quick Arm Enable
*23 Forced Bypass
*84 Auto STAY Arm
*176 Lack of Usage Option
Wireless Receiver and Transmitters
If using a wireless receiver, set the receiver’s address to “00” using its DIP switches, then program
the following options:
*22 RF Jam Option
*24 RF House ID Code (if using wireless touchpads) for each partition
*67 Transmitter Low Battery Report Code
*75 Transmitter Low battery restore report code
*173 RF Reporting Options
Pager Programming
The system can send various reports to up to four pagers. To program pager reporting, do the
following:
1. Enter the appropriate information in the following data fields
*160, *163, *166, *169 Pager Phone Numbers (for pagers 1-4 respectively)
*161, *164, *167, *170 Pager Prefix Characters (for pagers 1-4 respectively)
*162, *165, *168, *171 Pager Reporting Options by Partition (for pagers 1-4 respectively)
2. Enable Pager Delay, if desired, in field *172 (delays alarm reporting for ALL pagers)
3. Disable appropriate user open/close pager reports using the user attribute command
(master code + [8] + user no. + [#] [5] + [0]). Users that perform actions in partition 1 will, if
enabled, attempt to report to all pagers enabled for open\close reporting in partition 1. Users that
perform actions in partition 2 will, if enabled, attempt to report to all pagers enabled for
open\close reporting in partition 2.
4. If using latchkey pager report, define the latchkey report schedule using Scheduling mode (master
code + [#] [6] [4] then select event type “03”).
5. If using a function key to manually send a message to a pager, see Function Keys paragraph
below.
6. If reporting zone alarms and troubles to a pager, use *81 Zone List menu mode to assign the zones
associated with each pager (zone lists 9-12).
