4-3
Dialer Programming (
∗
40 –
∗
50)
FIELD TITLE and DATA ENTRIES EXPLANATION
*40
PABX Access Code
Enter up to 6 digits if PABX is needed to
access an outside line. Do not fill unused
spaces.
0–9, # + 11 for ‘
∗
’, # + 12 for ‘#’, # + 13 for a
pause (2 seconds)
To clear entries from field, press
∗
40
∗
. If fewer than 6 digits need to
be entered, exit by pressing [
∗
], which advances to the next field.
*41
Primary Phone No.
Enter up to 20 digits. Do not fill unused
spaces.
0–9, # + 11 for ‘
∗
’, # + 12 for ‘#’, # + 13 for a
pause (2 seconds)
If you enter fewer than 20 digits, exit by pressing [
∗
] and next field
number (e.g., 42). To clear entries from field, press
∗
41
∗
.
NOTE: Backup reporting (in which 8 calls are made to the secondary
phone number if no kissoff is received after 8 attempts to the
primary number) is automatic only if there is a secondary phone
number (field
∗
42).
*42
Secondary Phone No.
Enter up to 20 digits.
Do not fill unused
spaces.
0–9, # + 11 for ‘
✱
’, # + 12 for ‘#’, # + 13 for a
pause (2 seconds)
If you enter fewer than 20 digits, exit by pressing [
∗
] and next field
number (e.g., 43). To clear entries from field, press
∗
42
∗
. See backup
reporting note for field
∗
41.
*43
Partition 1 Subscriber ID No.
Enter digits 0–9; # + 15 for F.
Enter 4 or 10 digits, depending on report format selection in field
*48. To clear entries from field, press
∗
43
∗
. Automatically puts same
entries into field *45.
*45
Partition 2 Subscriber ID No.
Enter digits 0–9; # + 15 for F.
Enter 4 or 10 digits, depending on report format selection in field
*48. To clear entries from field, press
∗
45
∗
.
*47
Phone System Select
If Central Station Receiver
is
not
on WATS
line: 0 = Pulse Dial; 1 = Tone Dial
If Central Station Receiver
is
on WATS line:
2 = Pulse Dial; 3 = Tone Dial
Select the type of telephone service.
*48
Report Format
(Primary/Secondary)
5 = CID using 10-digit account number
7 = CID using 4-digit account no.
#14 = CID 4-digit account no. with shutdown
#15 = CID 10-digit account no. w/shutdown
Select for primary and secondary phone numbers either 4-digit or 10-
digit Contact ID account number format, or 4-digit/10-digit with
shutdown capability.
*49
Split/Dual Reporting
0 = disable (Backup report only).
1 - 5 (see table to right)
To Primary No. To Secondary No.
1 = alarms, restore, cancel others
2 = all except open/close, test open/close, test
3 = alarms, restore, cancel all
4 = all except open/close, test all
5 = all all
*50
15-Second Dialer Dela
Bur
lar
0 = no dialer delay
1 = 15-second delay
Provides delay of “BURGLARY ALARM” report to the central
station, which allows time for the subscriber to avoid a false alarm
transmission. This delay does not apply to zone type 24 alarms,
which are always sent as soon as they occur.
UL installations must be 0 (no delay).
*53
Misc. Fault Delay Time
0 = 15 secs 6 = 2-1/2 min #+12 = 8 min
1 = 30 secs 7 = 3 min #+13 = 10 min
2 = 45 secs 8 = 4 min #+14 = 12 min
3 = 60 secs 9 = 5 min #+15 = 15 min
4 = 90 secs #+10 = 6 min
5 = 2 min #+11 = 7 min
Used with zones assigned to zone type 25 and/or zones assigned to a
configurable zone type with fault delay on. This field lets you select a
zone response time of 15 seconds to 15 min. It can be assigned to
zones with sensors designed to provide a trouble indication when an
oil tank is low, or other similar application for critical condition
monitoring where a non-alarm response is desired.
To Next Page
