Safewatch Pro 3000 Installation Instructions
4-10
Configurable Zone Type Programming Fields
The system allows you to define up to four custom zone types, based on the options described below,
which can be assigned to zones that require customized responses. All of these zone types can be
programmed via the downloader. Configurable zone types 90 and 91 can also be programmed from a
touchpad using data fields *182-*185 described below.
*182
Configurable Zone Type 90
0-15 = entries for each of 10 digits
Make the appropriate entry for each digit, 1-10, based on the charts
below.
To calculate each digit’s entry, add the values of the selected
options in each of the digit’s columns shown in the respective chart
(one option per column). For example, to program Digit 2 for “alarm
response to short,” “auto restore on,” but not a “vent zone,” enter 5
(“1” for alarm short + “4” for auto restore yes + “0” for vent zone no).
*183
Zone Type 90 Report Codes
%0%61 -( <<<
8639&0) -( <<<
Enter the desired 3-digit Contact ID report codes for alarms and
troubles occurring on zones assigned to this zone type.
Press [
∗
] to accept and continue.
IMPORTANT: Check with the central station for a complete list of
Contact ID report codes. Make sure the codes assigned do not conflict
in meaning with existing Contact ID report codes.
*184
Configurable Zone Type 91
0-15 = entries for each of 10 digits
See field *182 for explanation of entries.
*185
Zone Type 91 Report Codes
%0%61 -( <<<
8639&0) -( <<<
See field *183 for explanation of entries.
Configurable Zone Type Options
Auto Restore
Faults on zones set for this option are cleared and restore messages sent upon
restoral of faults.
Vent Zone
Zones set for this option are ignored if faulted when arming the system, but
will be protected if the zone is later restored (e.g., an open window can be
ignored when arming, but if the window is later closed, it will be protected;
opening the window again causes an alarm.)
Bypass when Disarmed
Zones set for this option can be bypassed only while the system is disarmed.
Bypass when Armed
Zones set for this option can be bypassed while the system is armed or
disarmed.
Dial Delay
Alarms on zones set for this option participate in dial delay central station
reporting, if system dial delay enabled in field *51.
Fault Delay
Faults on zones set for this option are delayed by the time set in field *53. Do
not use this option if using entry/exit delay for this zone type.
Faults Display
Selects how faults on zones set for this zone type are displayed.
Power Reset/Verification
Selects how the system responds to faults on zones.
Use Entry Delay 1/2
Selects whether to use the system’s entry delay times.
Use Exit Delay
Selects whether to use the system’s exit delay time.
Interior Type
Zones set for this option are treated same as standard zone type 4 (bypasses
when armed STAY, faults displayed).
Alarm Sounds
Selects the type of alarms sound for zones
set for this zone type.
Bell Timeout
Alarm sounds on zones set for this option remain for the duration set in fields
*32 and *33.
Fire Zone
Zones set for this option respond in the same manner as if programmed for
zone type 9. Do not set fire zones to respond as a “fault” in digits 1-6.
Trouble Sounds
Selects the type of trouble sounds for zones set for this zone type.
Chime Enable
Zones set for this option cause a chime when Chime mode is on.
