4-1
SECTION 4
Data Field Programming
•••••••••••••••••••••••••••••••••••••••
About Data Field Programming
The following pages list this control’s data fields in numerical order. Field numbers are listed in the
left column, followed by a “Title and Data Entries column, which lists the valid entries for each field.
Experienced installers can simply follow this column when programming the data fields. The
“Explanation” column provides explanatory information and special notes where applicable.
Use the blank programming form to record the data for this installation.
Programming Data Fields
Data field programming involves making the appropriate entries for each of the data fields.
Start Data Field programming by entering the installer code + 8 + 0 + 0.
System Setup Fields (
∗
20 – ∗29)
FIELD TITLE and DATA ENTRIES EXPLANATION
*20
Installer Code
Enter 4 digits, 0-9
The Installer Code is used to assign the 4-digit Master Security Code.
See "Master Code" in the
System Operation
section
for procedure.
*21
Quick Arm Enable
0 = do not allow quick arm
1 = allow quick arm
If enabled, a user code is not needed to arm the system. Instead,
users can press the [#] followed by an arming key to arm the system.
However, the user code is always needed to disarm the system.
*22
RF Jam Option
0 = no RF jam detection
1 = send RF jam report
If enabled, a report is sent if the system detects an RF jamming
signal.
*23
Forced Bypass
0 = no forced bypass
1 = automatically bypass all faulted zones
All zones bypassed by this function will be displayed after the bypass
is initiated. UL installations must be 0 (no forced bypass)
*24
RF House ID Code
00 = disable all wireless touchpad usage
01–31 = House ID for partition 1, 2 and
common
The House ID identifies receivers and wireless touchpads. If a 5827
or 5827BD Wireless Touchpad or 5804BD Transmitter is being used,
a House ID code
must
be entered, and the touchpad should be set to
the same House ID. You can assign RF house ID for each partition.
*26
Chime By Zone [List]
0 = no zone list (chimes on fault of
any
entry/exit or perimeter zone when chime
mode on)
1 = use zone list (chimes on fault of
specific
zones programmed in relay
zone list 3 when Chime mode on)
If enabled, you can define the specific zones intended to chime when
faulted while the system is in Chime mode. Use zone list 3 to assign
these zones (see
∗
81
Zone List Programming
section for details).
*27
Powerline Carrier Device (X-10)
House ID
0 = A 6 = G # + 11 = L
1 = B 7 = H # + 12 = M
2 = C 8 = I # + 13 = N
3 = D 9 = J # + 14 = O
4 = E # + 10 = K # + 15 = P
5 = F
Powerline Carrier devices require a House ID, identified in this field.
Program Powerline Carrier devices in interactive modes
∗
79, *80 and
*81.
*28
Access Code for Phone Module
1-9 = first digit of access code
∗
or # = second digit of access code (enter #
+11 for “
∗
”, or # +12 for “#”)
You need to assign a 2-digit access code for the 4285/4286 Phone
Module, if used.
Example: If desired access code is 7
∗
, 7 is the first entry, and [#] + 11
(for
∗
) is the second entry.
NOTE:
A “0” in either digit disables the phone module.
