PROMPT VALID ENTRIES EXPLANATION
10 INPUT S/N: L
AXXX-XXX –
Serial number
S/N = serial number
L = loop number
[
∗
] to continue
Manually enter the serial number (found on the transmitter label),
by typing digits in the “X” locations, using the [A] (advance) or [B]
(back) keys as required. You can also perform two open and close
sequences; for button-type transmitters that means pressing and
releasing the button twice.
NOTE
:
If you want to copy the previous zone’s serial number, press
the [C] key.
Press [
✱
] to advance to the loop number, then enter loop number.
Press [
✱
] to accept the existing serial and loop number and continue
to the “Confirm” prompt below. If necessary, press [#] to back up and
re-enter or edit the serial number.
10 INPUT S/N:
L
A000-0000 0
To Delete a Serial
Number
[
∗
] to continue
To delete an existing serial number, enter 0 in the loop number
field. The serial number will change to all 0's as shown.
If 0 was entered in error, simply re-enter the loop number, and the
serial number will return to the display.
10 XMIT TO CONFIRM
PRESS
✱
TO SKIP
Confirm
[
∗
] to continue
The prompt to confirm appears
.
This prompt will only appear if the
first prompt after entering
✱
58 was answered “Yes.” To confirm,
activate the loop input or button that corresponds to this zone.
The system checks for duplicate. If a duplicate exists, a long error
beep will sound.
Press [#] to back up and re-enter the serial and/or loop number.
Entd A022-4063
Rcvd A022-4064
If Serial or Loop
Numbers do not match
after activating the
transmitter
[
∗
] to continue
I
f the serial/loop number combination transmitted does not match
the serial and loop number entered, a display similar to the one
below will appear. If the loop number does not match, it will
also be displayed. If so, activate the transmitter’s loop input or
button one or more times.
If a match is still not obtained (i.e., summary display does not
appear), press the [#] key twice and enter the correct loop input or, if
correct, press [#] again and then enter the correct serial number.
Zn ZT P RC In L
10 03 1 10 RF:
1s
Note that an “s”
indicates that a
transmitter’s serial
number has been
enrolled.
Summary Screen
[
∗
] to continue
If the serial number transmitted matches the serial number entered,
the keypad will beep 3 times and a summary display will appear,
showing the programmed information for that zone.
Press [
✱
] to begin programming the next zone. See first “Summary
Screen” prompt paragraph on previous page.
