3000EN Series: Installation Instructions
6-4
01 Activated By:
Zone List
Activated By
0 = delete
1 = zone list
2 = zone type
3 = zone number
[∗] to continue
Select where the initiating event for this output definition is
to occur as follows:
0 = delete (deletes the output function and any previous
programming;-see prompt below)
1 = zone list (go to “A” prompt)
2 = zone type (go to “B” prompt)
3 = zone number (go to “C” prompt)
If you enter “0,” the following prompt appears:
Delete? Press 1 to delete this
0 = NO, 1 = YES output definition.
“A”
01 Zn List
1
Zone List
01-08 = zone list
[∗] to continue
If zone list was selected, this screen appears. Otherwise skip to
the next row.
Enter the desired zone list associated with this output number.
NOTE: Do not use pager zone lists 09-12 in output definitions.
Press [
✱
] to continue.
Enter the zone list event that will activate this output.
Enter Event 0 = restore; 1 = alarm;
Alarm 1 2 = fault; 3= trouble
NOTE: For alarm, fault, and trouble, an event on ANY zone in
the list activates the output, but ALL zones in the list must be
restored before the output is restored.
Press [
✱
] to continue and skip to the “Output Action” prompt.
“B”
01 Enter Zn type
Perimeter 03
Zone Type
see list at right
If zone type was selected, this screen appears. Otherwise skip
to the next row.
Enter the desired zone type associated with this output
number. See below for a list of available zone types.
CHOICES FOR ZONE TYPES:
00 = Not Used 05 = Trouble Day/Alarm Night 14 = Carbon Monoxide††
01 = Ent/Exit #1 06 = 24 Hr Silent 16 = Fire w/verification
02 = Ent/Exit #2 07 = 24 Hr Audible 23 = No Alarm Response
03 = Perimeter 08 = 24 Hr Aux 24 = Silent Burglary
04 = Interior Follower 09 = Fire 25 = 24-Hr Non-Alarm
10 = Interior w/Delay 77 = Keyswitch Zone
12 = Monitor Zone 81 = AAV Monitor Zone
90-93 = Configurable
CHOICES FOR SYSTEM OPERATION:
20 = Arming–Stay 36 = **At Bell Timeout*** 58 = Duress
21 = Arming–Away 38 = Chime 60 = AAV
22 = Disarming 39 = Any Fire Alarm 61 = AVS/GSMV
session begin §
31 = End of Exit Time 40 = Bypassing 62 = AVS/GSMV
session end §
32 = Start of Entry Time 41 = **AC Power Failure 66 = Function Key†
33 = Any Burglary Alarm 42 = **System Battery Low 67 = Bell Fail
43 = Comm. Failure 68 = Telco line cut
52 = Kissoff 78 = Keyswitch Red LED
54 = Fire Zone Reset 79 = Keyswitch Green LED
** Use 0 (Any) for Partition No. (P) entry.
*** Or at Disarming, whichever occurs earlier.
†
Use *57 Menu Mode to assign the function key (function “07”).
†† when used with an output function, the carbon monoxide zone type
activates upon CO alarms only. Does not activate for trouble condition
s
§ automatically set when appropriate AVS Quick Command performed
.
Note: In normal operation mode:
Code + # + 7 + NN Key Entry starts Device NN.
Code + # + 8 + NN Key Entry stops Device NN.
Enter the partition in which this zone type will occur.
01 Partition 0 = any partition; 1 = partition 1;
Any partition 0 2 = partition 2; 3 = common
Press [
✱
] to continue and skip to the “Output Action” prompt.
