6-5
“C”
01 Enter Zn No.
12
Zone Number
If zone number was selected, this screen appears.
Enter the desired zone number associated with this output
number.
Press [
✱
] to continue.
Enter the zone event that will activate this output.
01 Enter Event 0 = restore; 1 = alarm/fault/trouble
Restore 0
Press [
✱
] to continue to the “Output Action” prompt
01 Output Action
Close for 2 sec 1
Output Action
0-6 = see list at right.
Enter the desired device action as listed below. Press the [
✱
]
key to continue.
0 = off 4 = Change Device State
1 = Close for 2 seconds 5 = Duration 1 (see data field *177)
2 = Stay Closed 6 = Duration 2 (see data field *177)
3 = Pulse one second ON, one second OFF)
Enter Output No.
R02 02
Output Number
01-18 = output number
Enter the device output number (programmed in *79 Menu
Mode) you want associated with this output.
Press [
✱
] to continue.
02 A E P TRIG
R02 1 1 3 ZL=00
Summary Screen
A summary screen appears showing the programmed settings.
Press [
✱
] to continue.
