Adtech CNC Technology Co., Ltd. 11. System parameters
- 53 -
009
X FastSpeed(mm/min)
010 FastSpeed(mm/min)
011 Z FastSpeed(mm/min)
012 4 FastSpeed(mm/min)
013
XStartupSpeed(mm/min)
014 YStartupSpeed(mm/min)
015 ZStartupSpeed(mm/min)
016 4StartupSpeed(mm/min)
017
X Acceleration(Kpps)
018 Y Acceleration(Kpps)
019 Z Acceleration(Kpps)
020 4 Acceleration(Kpps)
Range : 1~9999, 1~9999, 1~8000
Unit : mm/min,mm/min,mm/sec
Authority : Operation admin or higher
Default : 3000,200,1500
Effective time : Instant
Note : This parameter is the trapezoid acceleration/deceleration setting and used
for GOO instruction
About start speed, 1-2 rotation motor speed is recommended for step
motor; as above, the machine tool moves 5mm when the motor rotates
one cycle, and the speed is 5-10mm/sec (300-600mm/min). For servo
motor, the start and stop shouldn’t have vibration. If this speed is too high,
it will cause vibration during motion, and the step motor will be out of
step.
The acceleration and start speed also affect manual speed, home speed,
etc.;
021
X Soft PosLimit+(mm)
022 X Soft PosLimit-(mm)
023 Y Soft PosLimit+(mm)
024 Y Soft PosLimit-(mm)
025 Z Soft PosLimit+(mm)
026 Z Soft PosLimit-(mm)
027 4 Soft PosLimit+(mm)
028 4 Soft PosLimit-(mm)
Range : -9999~9999
Unit : mm
Authority : Operation admin or higher
Default : Maximum positive/negative value
Effective time : Instant
Note : Generally, the machine tool has hard limit signal. In this case, software
limit isn’t required. Please set the positive limit to +9999.999, and
negative limit to -9999.999.
If hard limit switch isn’t installed, please use soft limit, which uses
machine tool coordinate system as the base point. Positive limit and
negative limit are subject to actual distance (unit: mm).
Since soft limit decelerates and stops at the limit point, it may exceed the
set distance, which depends on acceleration time and speed. Please keep
certain margin when setting this parameter.
