Adtech ADT-CNC4620 User Manual

Adtech CNC Technology Co., Ltd. 11. Program saving & editing
- 74 -
rotation directly later, while the controller will output corresponding
analog voltage according to linear scale automatically.
022 Spi.Gear Numerator
023 Spi.Gear Denominator
Range : 1~65535
Unit : None
Authority : Operation admin or higher
Default : 1
Effective time : Instant
Note : If the principal axis has gear position, please set the hardware gear ratio
to this parameter, which hasn’t been used in standard version, but may be
used in certain special conditions.
11.7 Port configuration (P6.)
001 Wheel0.1-------- Input wire No.
… …
014 4 Alarm------ Input wire No.
Range : 0~24
Unit : None
Authority : Super Admin
Default : The port table in the manual
Effective time : Instant
Note : Handheld box interface and servo alarm function pin definition;
Type 8888 and press Insert, the system won’t map and will use the
default wire No. in the manual. If the operation is successful, it displays
“=======”;
Input value 1~24: map to corresponding pin on IO board
015 IN0-------- Input wire No.
… …
038 IN23------- Input wire No.
Range : 1~24
Unit : None
Authority : Super Admin
Default : The port table in the manual
Effective time : Instant
Note : Input terminal No. configuration parameter
Terminal No. is the object of the system to control IO, e.g. X external
home signal test, the system tests terminal No. IN0, which corresponds to
input wire 1 by default, and thus the system tests input pin1 indirectly; by
default, the terminal No. is assigned to wire No. according to the IO
relationship in the manual; however, this relationship isn’t constant, and
you can specify in these parameters and reassign a terminal No. to any
input port;
For example, if you set 10 in parameter 042, the system will test pin 10
instead of pin 1 when it tests X home signal during home operation.
039 OUT0-------- Output wire No.
… …
062 OUT23------- Input wire No.
Range : 1~24
Unit : None
Authority : Super Admin
Default : The port table in the manual
Effective time : Instant
