Adtech ADT-CNC4620 User Manual

Adtech CNC Technology Co., Ltd. 11. System parameters
- 63 -
and the default value is off.
Scanning mode is integrated by the system and can’t be shielded. The
scanning mode inputs signal by accessing specified function number, and
uses software anti-interference detection technology to check whether limit
alarm occurs or has no interference. This requires certain time to check, and
thus the real time isn’t as well as interrupted limit. However, in most cases (at
10mm/min processing speed), it can meet the requirement on processing
safety check.
The hardware response function of hard limit is prior to scanning response
function, i.e. if the hardware response is enabled, it will quicken the response
speed directly. It should be noted that the hardware response function only
can stop pulse in instant mode. Therefore, the instant stop mode may cause
mechanical vibration if the speed is too high. While software scanning mode
uses maximum acceleration mode and decelerates according to the maximum
acceleration set to every axis by the user (parameter P2.074~077), and
therefore overshot will occur.
029
X Pulse Mode<●>
030
Y Pulse Mode<●>
031
Z Pulse Mode<●>
032
4 Pulse Mode<●>
Range : 0~1
Unit : None
Authority : Super Admin
Default : 1
Effective time : Restart
Note : Pulse command format setting is to configure the mode of output pulse.
The compatible command format of the motor drive should be known in
advance.
Pulse + pulse
Pulse + direction
033
X Pulse Dir Mode<●>
034
Y Pulse Dir Mode<●>
035
Z Pulse Dir Mode<●>
036
4 Pulse Dir Mode<●>
Range : 0~1
Unit : None
Authority : Super Admin
Default : 1
Effective time : Restart
Note : Set pulse direction; if the controller direction is reverse to actual drive
direction, please modify this parameter to adjust the rotation direction of
motor.
037 X Ext Home ELevel
038 Y Ext Home ELevel
039 Z Ext Home ELevel
040 A Ext Home ELevel
Range : 0~1
Unit : LOGIC VOLTAGE LEVEL
Authority : Super Admin
Default : 0
Effective time : Instant
Note : Set the effective voltage level of external home sensor switch during
home operation.
Low level
High level
041 X Round Setting
