Adtech ADT-CNC4620 User Manual

Adtech CNC Technology Co., Ltd. 11. System parameters
- 65 -
Unit : Wire number
Authority : Super Admin
Default : 2500
Effective time : Instant
Note : Set the encoder wires connected to every pulse port (AB phase pulse).
Since four times frequency division is performed for internal transfer, the
value of this parameter should be the pulses collected by the encoder for
one cycle divided by 4.
058
X PulseLogic Level<●>
059
Y PulseLogic Level<●>
060
Z PulseLogic Level<●>
061
4 PulseLogic Level<●>
Range : 0~1
Unit : LOGIC VOLTAGE LEVEL
Authority : Super Admin
Default : 0
Effective time : Restart
Note : Set the normal voltage level when the pulse is working. If the setting is
different from the normal voltage level required by motor drive, a
direction will have accumulative error during every positive and negative
motion (independent of pulses). Therefore, if the positioning axis of the
machine has accumulative error in a direction, please check whether this
parameter matches.
