Adtech CNC Technology Co., Ltd. 11. Program saving & editing
- 68 -
086
X Encoder LogicDir<●>
087
Y Encoder LogicDir<●>
088
Z Encoder LogicDir<●>
089
4 Encoder LogicDir<●>
Range : 0~1
Unit : None
Authority : Super Admin
Default : 0
Effective time : Instant
Note : If the logic direction obtained by the encoder is reverse to the actual
motion direction of the axis, please set this parameter.
Handwheel encoder reuses A axis encoder.
Principal axis encoder reuses X axis encoder.
0: Positive
1: Negative
090 X HomeSpeed2
091 Y HomeSpeed2
092 Z HomeSpeed2
093 4 HomeSpeed2
094 X HomeSpeed3
095 Y HomeSpeed3
096 Z HomeSpeed3
097 4 HomeSpeed3
Range : 1~20000
Unit : mm/min
Authority : Super Admin
Default : 100, 60
Effective time : Instant
Note : Used to set the speed parameters of mechanical resetting; the specific
effective sequence follows:
Resetting speed ——> (when detecting external zero switch) deceleration
——> scanning speed
100 hand wheel encoder dir
Range : 0~1
Unit : None
Authority : Super Admin
Default : 0
Effective time : Instant
Note : When the logic direction obtained by handheld box encoder is reverse to
the actual motion direction of the axis, set this parameter to perform
in-phase setting.
0: positive direction
1: negative direction
101 X restrain acc (mm/s^2)
102 Y restrain acc (mm/s^2)
103 Z restrain acc (mm/s^2)
104 4 restrain acc (mm/s^2)
105 X max restrain rate
106 Y max restrain rate
107 Z max restrain rate
108 4 max restrain rate
