Adtech CNC9650 User Manual

ADTECH9 Series CNC Maintenance Manual
- 9 -
Function Name Specification
Reverse clearance compensation
Yes
Other functions
Measurement centered
Automatic tool regulator
Yes
Specify arc radius R/center position
Yes
Electronic gear ratio
Yes
1.2 System operating condition
Operating voltage 24V DC (with filter)
Operating temperature
0℃-45℃
Optimum operating temperature
5℃-40℃
Operating humidity 10%-90% (no condensing)
Optimum operating humidity 20%-85%
Storage temperature
0℃-50℃
Storage humidity 10%-90%
Operating environment
No excessive dust, acid, alkali, corrosive and explosive gases, no strong
electromagnetic interference
1.3 System function
1.3.1. Self-diagnosis function
Diagnose CPU, memory, LCD, I/O interface, parameter state, coordinates and processing program
comprehensively every time the system is started or reset; diagnose power supply, spindle, limit and I/O ports in
real-time during operating.
1.3.2. Compensation
Automatic reverse clearance compensation
Automatic tool length compensation
Automatic tool radius compensation
Automatic tool radius biasing and automatic tool tip transition
1.3.3. Abundant instruction system
Scaling instruction
Mirror processing instruction
Tool biasing instructions

Adtech CNC9650 Specifications

General

Brand	Adtech
Model	CNC9650
Category	Control Systems
Language	English
