ADTECH9 Series CNC Maintenance Manual

- 193 -

1 IN0 X axis home

2 IN1 Y axis home

3 IN2 Z axis home

4 IN3 Z axis home

5 IN4 Standby input

6 IN5 Standby input

7 IN6 Standby input

8 IN7 Standby input

9 IN8 Standby input

10 IN9 Standby input

11 IN10 Standby input

12 IN11 Standby input

13 IN12 Standby input

14 IN13 Standby input

15 IN14 Standby input

16 IN15 Standby input

17 IN16(XLMT-) X axis negative limit

18 IN17(XLMT+) X axis positive limit

19 IN18(YLMT-) Y axis negative limit

20 IN19(YLMT+) Y axis positive limit

21 IN20(ZLMT-) Z axis negative limit

22 IN21(ZLMT+) Z axis positive limit

23 IN22(ALMT-) A axis negative limit

24 IN23(ALMT+) A axis positive limit

25 INCOM

Input common end INCOM (24V+, 12V+) connects

to internal or external power supply

Default input port configuration of 98M series XS5 (CNC9810 milling machine)

Wire No. Port Definition Function

1 IN0 X axis home

2 IN1 Y axis home

3 IN2 Z axis home

4 IN3 Z axis home
