ADTECH9 Series CNC Maintenance Manual
- 201 -
22 OUT21 (M46, M47) (operation panel F3 M46, M47)
23 OUT22 (M48, M49) (operation panel F4 M48, M49)
24 OUT23 (M50, M51) (FCNC6D panel F5 M50, M51)
25
OUTGND12V-, 24V- common power supply of
external output
Default configuration of extended output port of M series milling machine CNC9960 (XS15)
Wire No. Port Definition Function
1 OUT24 (FCNC6D panel F6 M52, M53)
2 OUT25 (FCNC6D panel F7 M54, M55)
3 OUT26 (FCNC6D panel F8 M56, M57)
4 OUT27 (FCNC6D panel F9 M58, M59)
5 OUT28 (FCNC6D panel F10 M60, M61)
6 OUT29 (FCNC6D panel F11 M62, M63)
7 OUT30 (FCNC6D panel F12 M64, M65)
8 OUT31 (FCNC6D panel F13 M66, M67)
9 OUT32 (Standby output M68, M69)
10 OUT33 (Standby output M70, M71)
11 OUT34 (Standby output M72, M73)
12 OUT35 (Standby output M74, M75)
13 OUT36 (Standby output M76, M77)
14 OUT37 (Standby output M78, M79)
15 OUT38 (Standby output M80, M81)
16 OUT39 (Standby output M82, M83)
17 OUT40 (Standby output M84, M85)
18 OUT41 (Standby output M86, M87)
19 OUT42 (Standby output M90, M91)
20 OUT43 (Standby output M92, M93)
21 OUT44 (Standby output M94, M95)
22 OUT45 (Standby output M96, M97)
23 OUT46 (Standby output M198, M199)
24 OUT47 (Standby output M100, M101)
