ADTECH9 Series CNC Maintenance Manual
- 235 -
ET102A splitter function definition (Extended input 2—external expansion)
Termina
l No.
Area Port Name Extended input of Standard system
J38
POWER
+24V 24V power supply output terminal
J38 GND 24V power supply output GND terminal
J38
IN03-IN00
IN00 Standby IN100
J38 IN01 Standby IN101
J38 IN02 Standby IN102
J38 IN03 Standby IN103
J38
POWER
+24V 24V power supply output terminal
J38 GND 24V power supply output GND terminal
J38
IN07-IN04
IN04 Standby IN104
J38 IN05 Standby IN105
J38 IN06 Standby IN106
J38 IN07 Standby IN107
J38
POWER
+24V 24V power supply output terminal
J38 GND 24V power supply output GND terminal
J38
IN11-IN08
IN08 Standby IN108
J38 IN09 Standby IN109
J38 IN10 Standby IN110
J38 IN11 Standby IN111
J39
POWER
+24V 24V power supply output terminal
J39 GND 24V power supply output GND terminal
J39
IN15-IN12
IN12 Standby IN112
J39 IN13 Standby IN113
J39 IN14 Standby IN114
J39 IN15 Standby IN115
J39
POWER
+24V 24V power supply output terminal
J39 GND 24V power supply output GND terminal
J39
IN19-IN16
IN16 Standby IN116
J39 IN17 Standby IN117
