Adtech DJ8849V1-A01 User Manual

User Manual of TV5600-B01 Series Dispensing Control System
52
7.05 Other file parameters
1. ->In handheld box file parameter interface -> Press [ Other parameters] ->> enter
parameters
Parameter
Description(blue characters indicatethe parameters open to the simplified
interface)
Other
parameters
1) Cycle processing times: The number of products processed in the current file
cycle. 0 indicates unlimited time. To achieve cyclic machining, set the machining
mode to cycle
2) Default needle lift height: The default needle height for the end point and
single point command
3) Arc speed clamping factor: Arc clamp speed
4) Whether to use safe height function: Whether the Z-axis safe height function is
enabled
5) Z-axis safe height: Safe height in Z machining
6) Automatic fillet error range: The distance between the maximum cut edge and

Adtech DJ8849V1-A01 Specifications

General

Brand	Adtech
Model	DJ8849V1-A01
Category	Control Systems
Language	English
