User Manual of TV5600-B01 Series Dispensing Control System
55
Enter parameters ->
Factory parameters include some basic configurations such as input and output, motor features,
and configuration
8.01.01 Motor feature parameters
1. ->In handheld box system parameter interface -> Press [ Factory parameters] ->
enter motor feature parameters ->
Parameter
Description
Motor features
1) Pulse equivalent: Refers to the distance of a pulse corresponding to the
actual movement of the motor
2) Pulse equivalent setting wizard: The pulse equivalent can be calculated
according to the step settings of the wizard
3) Pulse transmission mode: According to the driver setting mode, it can be
divided into pulse + direction and pulse + pulse
4) Reset mode: There are seven modes: reciprocating reset, circumferential
