User Manual of TV5600-B01 Series Dispensing Control System
can use this time as the delay. When the time is up, it will automatically
return to the loading position. Only one of the two modes can be selected
5) Loading position: The position where the Y axis arrives before starting; the
left and right positions are the same; the actual coordinates are input
6) Unloading position: The position where the Y axis arrives after the machining
is completed; the left and right positions are the same; the actual
coordinates are input
Rotation
parameters
(not available
for
DJ904V1-A01
and
DJ8849V1-A01
)
1) Glue gun rotation radius: The angle of the circle drawn by the needle when
the glue gun is tilted and the R axis rotates one revolution
2) Offset angle of glue gun rotation: The angle between the needle and the
positive X direction after the R axis is reset
3) Glue rotation parameter setting wizard: According to the teaching steps of
this interface, the teaching of the rotation radius of the glue gun and the
offset angle of the glue gun rotation can be completed
4) Workpiece rotation plane: There are three rotation planes: XY, XZ and YZ.
The plane perpendicular to the rotation axis is selected as the rotation plane
5) XYZ coordinate of workpiece rotation center: Important parameters of
workpiece rotation, need to be set before editing the machining file, or
elseprocessing will have error
6) Workpiece rotation center teaching: According to the teaching steps of the
interface, the teaching of the workpiece rotation center can be completed
Visual
dispensing
parameters
(not available
for
DJ904V1-A01
and
DJ8849V1-A01
)
1) Correction function: Single product correction is to correct the deviation of a
product, and multiple product correction is to correct some products
separately
2) CCD shooting mode: One correction applies to the camera with high pixel.
Two correctionsneed totake two MARK points
3) File teaching mode: The camera teaching point is to teach the track through
high. The needle teaching point is taught according to the actual needle
position, and the teaching speed is fast
4) Photo debounce time (ms): The delay before taking picture when the camera
moves to the shooting position
5) Data receiving timeout (ms): Timeout period for the controller to receive
visual data
6) Calibration position setting: Calibrate the needle with the camera to obtain
the distance between the two
7) CCD debugging switch: Usually used by developers to turn on visual script
debugging switch
Network
parameter
configuration
1) Network MAC: Set the MAC address
2) Local IP: Set the IP address of the local controller
3) Remote network IP: Set the IP address of the visual controller [for visual
dispensing]
4) Client network port number: Network port number [for visual dispensing]
5) Local network port: Local network port number
