Advanced Poly-Packaging T-1000 - Spare Parts Kit

5.26 SP-20 Spare Parts Kit (Level 2) (P/N T-SP-20)
APPI P/N Qty Description APPI P/N Qty Description
TP-T1MA00115 2 Brake Tension Strap TP-300500 2 PTFE Sheet
TP-T1MN00041 1 Main Seal Cylinder TP-306002 2 Anti-Jam Seal Rubber
TP-T1MC00055 1 Brake Bushing TP-401254 2 Tee Fitting 1/4 Poly
TP-T1MC00124-1 1 High Voltage Sensor (Top) TP-401255 1 Elbow 3/8
TP-T1ME00301 1 High Voltage Board Assy TP-401257 5 Elbow 1/4
TP-T1ME00208 1 Brake Coil Cable Harness TP-401258 3 Straight Fitting 1/4
TP-T1ME00209 1 Seal Bar Cable Harness TP-401275 1 Elbow 3/8 x 1/8
HP-35027A1 2 Sponge Replacement TP-401276 1 Straight Fitting 3/8
TP-108155 2 Compression Spring TP-401277 4 Elbow 1/4 x 10/32
TP-111010 4 Collars, Spring Closure TP-401291 2 Elbow 1/4 x 1/4
TP-200348 1 Interface Board TP-402184 1 Flow Control
TP-202216 1 Capacitor 6000uF TP-402255 1 Valve (3000 series)
TP-205108 1 Filter (Corcom Line) TP-402256 1 Valve (5000 series)
TP-206146 1 25 Amp Triac TP-403243 1 Web Brake Cylinder
TP-207206 3 Fuse, (2.5 amp) TP-403244 1 Cylinder (Main Seal)
TP-207216 1 Fuse Holder TP-403245 1 Cylinder (Heater Bar)
TP-207225 3 Fuse Fast (1 AMP) TP-404262 2 Bronze Muffler
TP-207226 2 Fuse (3.15 AMP) TP-404266
1
0’
Tubing, 1/4” blue
TP-207227 3 Fuse (5 AMP) TP-404267 5’ Tubing, 3/8” Blue
TP-207228 3 Fuse, (10 AMP) TP-405268 1 Air Knife
TP-207344 3 Fuse, (12 AMP) TP-406181 2 Filter, Micron Blower
TP-211391 1 Triad Dual Primary Trans TP-501127 1 Motor
TP-212350 1 Terminal TP-501130 1 Capacitor
TP-215200 2 Magnetic Switch TP-502101 1 Clutch
125
