7.5 Circuit Boards
PLC (Fig. 4-8)
Output Indicators (LEDs) Y
Air Pulse (SAV10)9
Clutch / Perf Sensor Circuit8
Trim Seal Blow Off (SAV5)7
Bag Tear Off (SAV6)6
Heater Bar (SAV2)5
Flat Seal Assembly (SAV7)4
Pressure Bar (SAV1)3
Motor Run / Standby (IF27)2
Auxiliary Output1
Heater Circuit0
Printer CommandF
Accumulating Funnel (SAV8)E
Load Shelf (SAV4)D
BrakeC
Load Shelf (SAV3)B
Blower (SAV9)A
