AUX-3 PIN-C, AUX-2 PIN-F, IF/BD J1 PIN-3 OR 4GREENPIN-F
AUX-2 (6 PIN CONN)
IF/BD J1 PIN-3 OR 4, AUX-1 PIN-F, AUX-3 PIN-CGREENPIN-F
IF/BD J4-PIN-6BLUEPIN-E
NANOT USEDPIN-D
IF/BD J4-PIN-7WHT/BUPIN-C
IF/BD J1-PIN-3 OR 4, FOOT SW. PIN-3WHT/GRNPIN-B
PLC INPUT PIN-20WHT/GRYPIN-A
FOOT SW. (3 PIN CONN)
PLC INPUT PIN-22WHT/ORGPIN-3
IF/BD J1-PIN-3 OR 4 WHT/GRNPIN-2
CORCOM STANDOFFGREENPIN-1
MAIN POWER SW.
NANOT USEDPIN-6
NANOT USEDPIN-5
PWR CORD, CORCOM LINE (NEU), AUX-3 PIN-G,LINE OUT PLUGWHITEPIN-4
AUX-3 PIN-3, CORCOM LINE (AC), LINE OUT PLUGBLACKPIN-3
FUSE PIN-2BLACKPIN-2
NANOT USEDPIN-1
MAIN FUSE
MAIN POWER SW. PIN-2BLACKPIN-2
PWR CORDBLACKPIN-1
LINE OUT PLUG
MAINPOWER SW. PIN-4WHITEWIR-3
CORCOM CASE GROUNDGREENWIR-2
MAIN POWER SW. PIN-3BLK WIREWIR-1
OPTICAL TOUCH BUTTON (4 PIN MOLEX)
PLAM BUTTON-2 (LEFT SIDE)
IF/BD J1 PIN-3 OR 4, PLAM BUTTOM-1 PIN-4GREENPIN-4
IF/BD J3 PIN-1WHT/BLK/BRNPIN-3
IF/BD J3 PIN-2TANPIN-2
IF/BD J1 PIN-7, PLAM BUTTOM-1 PIN-1ORGPIN-1
PALM BUTTOM-1 (RIGHT SIDE)
IF/BD J1 PIN-3 OR 4, PLAM BUTTOM-2 PIN-4GREENPIN-4
IF/BD J3 PIN-3WHT/BLK/GRYPIN-3
IF/BD J3 PIN-4GREYPIN-2
IF/BD J1 PIN-7, PLAM BUTTOM-2 PIN-1ORGPIN-1
OPTICAL PART SENSE/COUNT (4PIN MOLEX)
SENSER-2 (LEFT SIDE)
IF/BD J1 PIN-3 OR 4, SENSER-1 PIN-4GREENPIN-4
IF/BD J2 PIN-11, SENSER-1 PIN-3WHT/VIOPIN-3
IF/BD J2 PIN-12, SENSER-1 PIN-2VIOPIN-2
IF/BD J1 PIN-7, SENSER-1 PIN-1ORGPIN-1
SENSER-1 (RIGHT SIDE)
IF/BD J1 PIN-3 OR 4, SENSER-2 PIN-4GREENPIN-4
IF/BD J2 PIN-11, SENSER-2 PIN-3WHT/VIOPIN-3
IF/BD J2 PIN-12, SENSER-2 PIN-2VIOPIN-2
IF/BD J1 PIN-7, SENSER-2 PIN-1ORGPIN-1
