OPTICAL PART SENSE PIN-2VIOPIN-12
PLC INPUT PIN-5, OPT. PART SENSE PIN-3WHT/VIOPIN-11
J-3 (10 PIN CONN)
PLC OUTPUT PIN-7, AUX-3 PIN-EWHT/ORGPIN-10
PLC OUTPUT PIN-30PINKPIN-9
PLC OUTPUT PIN-28WHT/GRYPIN-8
PLC OUTPUT PIN-10BRNPIN-7
PLC OUTPUT PIN-14REDPIN-6
HV/BD J1-PIN-3ORGPIN-5
OPT. TOUCH BUTTON-1 PIN-2GRYPIN-4
PLC INPUT PIN-17, TOUCH BUTTON-1 PIN-3WHT/BLK/GRYPIN-3
OPT. TOUCH BUTTON-2 PIN-2TANPIN-2
PLC INPUT PIN-18, TOUCH BUTTON-2 PIN-3WHT/BLK/BRNPIN-1
J-4 (4 PIN CONN)
AUX-2 PIN-C, AUX-1 PIN-CWHT/BLPIN-7
AUX-2 PIN-E, AUX-1 PIN-EBLUEPIN-6
NANOT USEDPIN-5
NANOT USEDPIN-4
PLC OUTPUT PIN-29BLUEPIN-3
PLC INPUT PIN-16WHT/YELPIN-2
JAW OPEN SW. PIN-1YELPIN-1
J-5 (14 PIN CONN)
MOTOR PIN-1BLACKPIN-14
HEATER BAR PIN-1PURPLEPIN-13
AUX-3 PIN-BWHT/VIOPIN-12
AUX-3 PIN-AVIOPIN-11
BRAKE PIN-2PURPLEPIN-10
BRAKE PIN-1PURPLEPIN-9
CLUTCH PIN-2GRAYPIN-8
HV/BD J1-PIN-1BLUEPIN-7
CLUTCH PIN-1GRAYPIN-6
HEATER PIN-2, CORCOM-LOAD (NEUTRAL)WHITEPIN-5
T-1XFMR PIN-5, JUMPER TO IF/BD J-5-PIN-2, MOTOR PIN-3WHITEPIN-4
T-1XFMR PIN-4, JUMPER TO IF/BD J5-PIN-1BLACKPIN-2
T-1XFMR PIN-2, HV/BD J1-PIN-6WHITEPIN-2
T-1XFMR PIN-1, CORCOM-LOAD (AC)BLACKPIN-1
AUX-3 (10 PIN CONN)
IF/BD J2-PIN-7WHT/BLK/REDPIN-H
PLC INPUT PIN-3WHT/BLK/ORGPIN-I
PLC INPUT PIN-4YELPIN-H
MAIN POWER SW. PIN-4WHITEPIN-G
MAIN POWER SW. PIN-3BLACKPIN-F
PLC OUTPUT PIN-7WHT/ORGPIN-E
IF/BD J1 PIN-7ORGPIN-D
IF/BD J1 PIN--3 OR 4, AUX-1 PIN-F, AUX-2 PIN-FGREENPIN-C
IF/BD J5 PIN-12, AUX-1 PIN-BWHT/VIOPIN-B
IF/BD J5 PIN-11, AUX-1 PIN-AVIOPIN-A
AUX-1 (6 PIN CONN)
AUX-2 PIN-EBLPIN-E
NANOT USEDPIN-D
AUX-2 PIN-CWHT/BLPIN-C
AUX-3 PIN-BWHT/VIOPIN-B
AUX-3 PIN-AVIOPIN-A
