NANOT USEDPIN-30
NANOT USEDPIN-29
NANOT USEDPIN-28
NANOT USEDPIN-27
IF/BD J2-PIN-1WHT/REDPIN-26
NANOT USEDPIN-25
NANOT USEDPIN-24
SEAL BAR IN PIN-1WHT/BLK/BLPIN-23
FOOT SWITCH PIN-2WHT/ORGPIN-22
HV/BD J2-PIN-3REDPIN-21
AUX-2 PIN-AWHT/GRYPIN-20
JAM DETECT PIN-1PINKPIN-19
IF/BD J3-PIN-1WHT/BLK/BRNPIN-18
IF/BD J3-PIN-3WHT/BLK/GRYPIN-17
IF/BD J4-PIN-2WHT/YELPIN-16
IF/BD J2-PIN-4BRNPIN-15
SEAL BAR IN PIN-2WHT/GRNPIN-14
JAM DETECT PIN-2WHT/GRNPIN-13
IF/BD J1-PIN-3 OR 4WHT/GRNPIN-12
SEE NOTE:1WHT/GRNPIN-11
NANOT USEDPIN-10
NANOT USEDPIN-9
NANOT USEDPIN-8
NANOT USEDPIN-7
IF/BD J-2 PIN-9WHT/BLPIN-6
IF/BD J-2-PIN-11WHT/VIOPIN-5
AUX-3 PIN-HYELPIN-4
AUX-3 PIN-IWHT/BLK/ORGPIN-3
POWER SUPPLY (5 PIN CONN)
IF/BD J1-PIN-7GRNPIN-5
IF/BD J1-PIN-3 OR 4YELPIN-4
NAREMOVEDPIN-3
IF/BD J1-PIN-3 OR 4REDPIN-2
IF/BD J1-PIN-6BRNPIN-1
IF BOARD
J-1 (7 PIN CONN)
PLC POWER SUPPLY PIN-5GRNPIN-7
PLC POWER SUPPLY PIN-1BRNPIN-6
FILTER CAP (+) POS.REDPIN-5
NANOT USEDPIN-4
CORCOM GROUND, FELTER CAP (-)NEG.GRNPIN-3
T-1XFMR PIN-10REDPIN-2
T-1XFMR PIN-6REDPIN-1
J-2 (12 PIN CONN)
NANOT USEDPIN-10
PLC INPUT PIN-6WHT/BLPIN-9
PLC OUTPUT PIN-9WHT/BLK/GRNPIN-8
AUX-3 PIN-JWHT/BLK/REDPIN-7
NANOT USEDPIN-6
NANOT USEDPIN-5
PLC INPUT PIN-15BRNPIN-4
THEROCOUPLE (-) NEG. CONNREDPIN-3
THEROCOUPLE (+) POS. CONNWHITEPIN-2
PLC INPUT PIN-26WHT/REDPIN-1
142
