Advanced Poly-Packaging T-1000 - Pneumatic Valves; Cylinders

I.F. Board Connectors (Fig. 4-11)
See wiring diagram for connectors identification (J1 - J5)
Perf Sensor (P.S.) Board (Fig. 4-12)
See wiring diagramConnectorsJ1 - J4
Jumper 1 / 2 (normal)Jumper SettingsH1
Factory set onlyPerf Sensor Sensitivity AdjustmentR9
RedPerf Detected LightE3
GreenArmed Sensor LightE1
7.6 Pneumatic Valves / Cylinders
Pneumatic Piping Diagram (Fig. 4-13)
Air Pulse Air PulseValveSAV10
BlowerBlower ValveSAV9
Accum. Funnel Cylinder Accum. Funnel (Option)SAV8
Flat Seal Cyl.Flat Seal Sol Valve (Option)SAV7
Tear Off CylinderTear Off Sol ValveSAV6
Trim BlowerTrim Seal Sol Valve (Option)SAV5
Bag Lift CylinderLoad Shelf Sol Valve (Option)SAV4
Load Shelf CylinderLoad Shelf Sol Valve (Option)SAV3
Seal Bar Cylinders (2)Heat Bar Sol ValveSAV2
Main Seal CylinderPressure Bar Sol ValveSAV1
150
