7.1 Trouble Shooting Guide
The items included in this section cover the common causes of trouble which an operator might
encounter during the operation of the T-1000. When operating difficulties occur, the best
procedure is to observe what is happening; then search out the causes; and effect the correction.
Make only one adjustment at a time, checking the results of each adjustment. If an adjustment
does not help or escalates the problems, return the settings back to the former position.
CAUTION: These tests and repairs should be performed only by qualified mechanics or
electricians and at their own risk.
NOTE: When trouble shooting a T-1000 functioning within a system (e.g.: with conveyors,
scales, feeders, counters, etc.), always isolate the equipment and operate each machine
individually.
7.2 Troubleshooting Checklist
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
Touch Screen does
not display
1. Power off
2. Loose connection
3. Fuse blown
4. Contrast out of adjustment
1. Plug in power cord / turn on
2. Tighten connections
3. Replace fuse(s)
4. Adjust screen contrast
No main power
light
1. Blown fuse
2. Bulb out
1. Replace fuse
2. Replace bulb
Pressure bar does
not move when
foot switch is
operated
1. Disconnected air line/foot
switch
2. Power off
1. Hookup air line
2. Turn on power
Pressure bar
moves
inward but does
not
reach the front
plate
(retracts
immediately)
1. Anti-jam improperly adjusted
2. Misalignment of guide rods
3. Insufficient air pressure
4. Loose / broken ground wire
on
guide rods
1. Adjust anti-jam (section 4.10)
2. Align guide rods (section 4.8)
3. Increase air pressure
4. Connect / tighten ground wires
Pressure bar
presses against
front plate but
does not seal bag
1. Seal time too low
2. Heat (temp.) too low
3. Heater cartridge bad
4. Insufficient air pressure
5. Misalignment of guide rods
6. PTFE folded over
7. Heater bar not extending
8. Seal cylinder bad
9. Heater bar cylinder(s) bad
1. Increase in bag setup screen
2. Increase in bag setup screen
3. Replace heater cartridge
4. Increase air pressure
5. Align guide rods
6. Turn PTFE
7. Check heater bar cylinders / valve
8. Replace cylinder / valve
9. Replace cylinder / valve
