Advanced Poly-Packaging T-1000 - Page 136

Optical Touch (Palm) Button 1 (right side)
non-inverting input (current sink) to X-9 on
PLC. 23.6 volts indicates no input. 0 volts
indicates an input and lights E-7. Available
on Palm Button Plug 1-3 under right side
cover of machine.
0 V. D.C. or
23.6 V. D.C.
J1-3,4J3-3
Optical Touch (Palm) Button 2 (left side)
inverting input (current source) to inverting
input on I.F. Board. 0 volts indicates no input
from touch button. 24 volts indicates an input
and lights E-8. Available on Palm Button
Plug 2-2 under left side cover of machine.
0 V..D.C. or
24 V. D.C.
J1-3,4J3-2
Optical Touch (Palm) Button 2 (left side)
non-inverting input (current sink) to X-8 on
PLC. 23.6 volts indicates no input. 0 volts
indicates an input and lights E-8. Available
on Palm Button Plug 2-3 under left side cover
of machine.
0 V. D.C. or
23.6 V. D.C.
J1-3,4J3-1
Optical Part Sense/Count inverting input
(current source) to inverting input on I.F.
Board. 0 volts indicates no input. 24 volts
indicates a current sorcing input and lights
E9. Available on Optical Part Sense/Count
Sensor Plugs 1&2 under left and right covers
of the machine.
0 V D.C. or
24 V D.C.
J1-3,4J2-12
Optical Part Sense/ Count non-inverting input
(current sink) to X-D of PLC. 0 volts
indicates an input and lights E9. 23.6 volts
indicates no input. Available on Optical Part
Sense/Count Sensor Plugs 1&2 pin 3 under
left and right covers of the machine.
0 V. D.C. or
23.6 V D.C.
J1-3,4J2-11
Foil Out inverted input to I.F. Board. Not
Used
0 V D.C.J1-3,4J2-10
Foil Out input to X-C on PLC. Operates E10
when foil out. Connects to Aux.3-I on back of
bagger. 0 volts D.C. indicates foil out. 22.6
volts indicates run condition. Requires
common ground.
0 V D.C. or
22.6 V D.C.
J1-3,4J2-9
Bagger Run/Stop output command from PLC
Y-D to I.F. board. 0 volts equals run with E11
on 22.6 volts indicates stop.
0 V. D.C. or
22.6 V. D.C.
J1-3,4J2-8
Bagger Run/Stop command to auxiliary
equipment. E11 on indicates run. Voltage
determined by auxiliary equipment voltage on
Aux. Plug 3-J up to 24 V D.C.. Requires
joining D.C. Grounds on Aux.3-C. Current
sinking .1A;0 volts equals bagger run or not
connected. Other positive voltage indicates
bagger stop.
0 V. D.C. to
24V. D.C.
max.
J1-3,4J2-7
Unused interface diode circuit cathode (E12)Not UsedJ2-6
Unused interface diode circuit anode (E12).Not UsedJ2-5
