DS-980/DS-980GL User Man
ual
14
2.3.4
Power Input Connector
DS-980/DS-980GL comes with a DC-Jack hea
der that takes 12V DC-in external
power input at main layer
, and optional second 12V DC-in at bottom laye
r
.
Figure 2.13 DC input connector at ma
in layer
Figure 2.14 DC input connector at bottom layer
