DS-980/DS-980GL User Manu
al
Chapter 4
BIOS Settings
PCI Express Clock Gating [Enable
d]: Enabl
e/ Disabled PCI Express clock gat-
ing for each root port; Co
nfiguration options: [Disabled][Eanbled
].
DMI Link ASPM Control [Enabled]: Enabled/
Disabled the control of active st
ate
power management on SA side of the DMI link; Configuration o
ptions: [Dis-
abled].
PCIE Port 5 is assigned to LAN: Mini PCI Express & M.2.
Figure 4.29 PCI express Configuration
66
68
