DS-980/DS-980GL User Manual 28
3.12 How to Select Suitable Graphic Cards
DS-980/DS-980GL is designed for the expansion slot by PCI Express x16 slot at the
bottom layer in order to fulfill video wall solution with triple+ displays which depends
on what quantities of its outputs a graphic card is. Due to the limited space of DS-
980/DS-980GL bottom layer, there are below criteria to select your suitable graphic
card.
1. Foam factor: Low Profile
2. Bracket side: Long
3. Maximum GPU, TDP (Walt): 75W
4. Maximum board dimension (Unit: mm): 167.65(L) x 68.9(W)
Figure 3.13 Maximum board dimension (Unit: mm)
