Advantech L-Band Satellite Modulator - Figure 1.5: Sbm75 E Modulator Rear Panel; Rear Panel Description

Getting Started
1.3.3 Rear Panel Description
The SBM75e Modulator rear panel provides a number of connectors Further details, including pin-
outs are described in Chapter 2, Installation
ASI 1/2/3/4
Connectors
Ext Ref in
Connector
AC Power
Connector
Redundancy
Connector
1 PPS in
Connector
70/140 MHz
Out connector
Ethernet
Connector
ALARM
Connector
M&C Modulator
Connector
ON/OFF
Switch
RS485
Connector
L-Band out
Connector
Figure 1.5: SBM75e Modulator Rear Panel
1-6 SBM75e Series Modulator Installation and Operation Manual
