Advantech L-Band Satellite Modulator - Summary of Features

Getting Started
1.2 Summary of Features
1.2.1 Overview
The SBM75e Modulator supports all the major satellite standards, both Intelsat and DVB, in a one
rack unit chassis, if the appropriate options are enabled.
Figure 1.1: SBM75e Modulator Block Diagram
1.3 Guided Tour
1.3.1 Enclosure
The SBM75e Modulator can be fitted into a 1U high enclosure and may be used on a desktop or
rack mounted.
1.3.2 Front Panel Description
The SBM75e Modulator is provided with a VFD 40 x 2 character display, 7 status LEDs and a 16
button keypad.
LED
Indicators
Keypad
VFD
SBM75e Series Modulator Installation and Operation Manual
1-3
