Web GUI Monitoring & Control
4.6 SBM-75: Alarms
From the ‘Alarms’ window the user may configure alarms and/or warnings based on the
behaviour and status of the modulator. Warnings are displayed to the user while alarms initiate
the alarm relay.
Alarms or warnings may be viewed by selecting the Alarms tab on the window shown above. A
window, similar to that shown in Figure 4.9 is displayed.
4.6.1 Setting Alarms
To set an alarm:
1. Check the ‘Alarm Monitoring’ box next to the property on which you wish to generate an
alarm.
2. Change the default alarm threshold, if required. The units of the threshold are displayed to
the right of the text entry box.
Note
Some alarms have no user threshold.
3. Repeat steps 2 and 3 to add all required alarms
4. Select the ‘Update Monitor’ tab. This is necessary for successful arming of the alarms.
4.6.2 Setting Warnings
To set a Warning:
1. Check the ‘Warning Monitoring’ box next to the property on which you wish to generate a
warning.
2. Change the default warning threshold, if required. The units of the threshold are displayed to
the right of the text entry box.
Note
Some warnings have no user threshold.
3. Repeat steps 2 and 3 to add all required warnings.
4. Select the ‘Update Monitor’ tab. This is necessary for successful arming of the warnings.
SBM75e Series Modulator Installation and Operation Manual
4-11
