Web GUI Monitoring & Control
4.6.3.8 Output power out of specification
This property allows an alarm or warning to be raised if the output power level is outside the
calibration range.
4.6.4 Advanced Alarms
The alarm/warning properties of the 1:1 redundancy unit may be viewed by selecting the
Advanced alarm tab. A window, similar to that shown in Figure 4.10 is displayed.
Figure 4.10: Output Alarms Window
4.6.4.1 Active unit failure
This event allows an alarm or warning to be raised if the active unit is not locked.
4.6.4.2 Redundant unit failure
This event allows an alarm or warning to be raised if the redundant unit is not locked.
4.6.4.3 Redundancy cable disconnected
This event allows an alarm or warning to be raised if the redundancy cable is removed.
4.6.4.4 RF Switch unreadable
This event allows an alarm or warning to be raised if the redundancy RF switch can not be
monitored.
4.6.4.5 RF Switch Shorted
This event allows an alarm or warning to be raised if the RF switch is shorted.
4.6.4.6 NTP Server error
An alarm or warning will be generated when contact with the NTP server has been lost.
SBM75e Series Modulator Installation and Operation Manual
4-13
