Front Panel Monitoring & Control
Menu Item Operations
Card Information >
Reports card information such as feature keys and software version
Status >
Lists the status of the input and configuration. All parameters in this menu are
read only.
Configure >
Allows configuration of various parameters within the unit.
Settings >
All the instantaneous commands such as power level and output enable are
controlled here
BISS >
BISS controls and status displayed if enabled
Reboot Card >
Will prompt a question to reboot the card
Reset To Factory
Defaults >
Will prompt a question to reset the unit to the factory defaults
System Setup >
Allows configuration of card Ethernet address.
3.3.2.1 Card Information
The Software version of the card is displayed as well as all supported feature keys.
3.3.2.2 Status
Table 3.3: Status Menu
Menu Item Operations
FPGA :
The FPGA has been programmed and is functioning correctly. If it fails this suggests
a hardware fault or faulty upgrade. Read only.
Input:
The status of the input. If unlocked then this suggests the input bit rate is not as
expected. Read only.
Self Test :
The report of the self test which was run at start up, if this fails then please report
this to Advantech support.
Output Power :
If this does not report calibrated then please report this to Advantech support
Prog Baud Rate:
The programmed Baud rate in Sym/S. Read Only.
Prog Bit Rate:
The programmed bit rate in b/s. Read Only.
Actual Baud
Rate:
The Actual Baud rate which is required to match the incoming bit rate. Read Only.
Board Temp:
The Temperature of the board in Celsius. Read Only.
Core1 Temp:
The FPGA Core temperature in Celsius. Read Only.
Achieved Power :
The actual power level transmitted which should match the required power level
when operating within the calibrated range.
Ref. Setting :
Reports if the frequency is locked to an internal source or external
Re. Clock :
Reports the status of the reference source if it is locked.
Ref. Signal :
Reports if a signal is present at the reference source
CCM State >
Sub directory listing the status of CCM settings
Input Type ;
Off: not used; Main: Main input used; Spare: Redundant input
used.
Overflow : This will report OK or FIFO FULL
Sync : This will report the input is synchronised
Rate Measure : This will report the incoming bit rate in Kbit/s
STREAM x State
Sub directory listing the status of the settings for Stream X, this is only applicable if
ACM has been configured.
Input Type ;
Off: not used; Main: Main input used; Spare: Redundant input
used.
3-4 SBM75e Series Modulator Installation and Operation Manual
