Web GUI Monitoring & Control
4.1 Introduction
This chapter is provided to guide the user through the functions of the Graphical User Interface
(GUI). Following the information given for accessing the GUI, those web pages which deal
specifically with chassis functions will be described. Subsequent sections focus specifically on the
operation of the SBM-75 in DVB-S2 modes.
4.2 Requirements for Accessing the GUI
Any of the following popular web browsing clients have been tested for accessing the GUI:
Microsoft Internet Explorer (Version 6 or 7)
Mozilla Firefox (Version 1.0, 1.5 or 2.0)
Safari (Version 2.0)
Opera (Version 9.0)
Note:
The analyser feature (see Section ***) requires Java support. The JRE used must be version 1.4 or
higher. Any virtual machine could be used, but the Sun Microsystems JVM is recommended, and is
the only one officially supported.
4.2.1 Accessing the GUI
To access the GUI:
1. Enter the IP address or name of the SBR to be controlled in the browser address bar.
Note
The web server of the SBM-75 can be found at the default address http://port followed by the port
number i.e. port 80.
The following window is displayed.
SBM75e Series Modulator Installation and Operation Manual
4-3
