Web GUI Monitoring & Control
4.4.1.4 Supported Features
A list of optional features supported by the unit is shown below the MAC address and is detailed
in Table 4.1.
Table 4.1: Optional Supported Features
Feature Operations
DVB-s
If the text ‘DVB-S’ is displayed, this indicates that the SBM-75 is able to
operate in DVB-S mode.
DVB-S (QPSK, 8PSK)
If the text ‘DVB-S (QPSK, 8PSK)’ is displayed, this indicates that the SBM-
75 is able to operate in this mode.
BISS (Basic
Interoperable Scrambling
System)
If the text ‘BISS’ is displayed, this indicates that the SBM-75 is able to
operate in this mode.
4.4.1.5 Capture System Snapshot
By activating this link a snapshot of the unit set up will be saved, this will create a binary file which
can be sent if there are any support issues.
.
4.4.1.6 Factory defaults
This will put the unit into a default state
4.5 SBM-75: Status
A basic summary of the operation of the SBM-75 may be viewed by selecting the Status Tab from
the window shown in Figure 4.6. A window, similar to that shown in Figure 4.8 is displayed.
i
SBM75e Series Modulator Installation and Operation Manual
4-9
