Front Panel Monitoring & Control
MUX_A:
MUX_B:
Note
The down arrow indicates that there are more profiles available. 10 profiles are currently supported.
3. Select the required profile. The following warning screen is displayed.
Loading Profile: MUX_A
ENTER = Confirm : CLEAR = Cancel
The new configuration will be pending until the unit is reconfigured.
To create and save a new profile:
1. Select the Create Profile option from the Profiles sub-menu. The following screen is displayed.
Name Profile:
Save Profile:
Note
Until a profile has been named, it cannot be saved and will not appear on the menu.
2. Select the Name Profile option. The following screen is displayed.
MUX_B Delete
ABCDEFGHIJKLMNOPQRSTUVWXYZ Select
3. Use the left and right arrows to navigate to the character required or use the numeric pad
0-9 to enter numbers.
4. Press the down arrow to select the character and the up arrow to delete.
5. When the name entry is complete, press the ENTER key.
Note
A total of 30 upper case characters can be entered on the front panel display. When using the GUI, up
to 64 upper and lower case characters may be entered.
6. Select the Save option. The following screen is displayed.
Saving Profile: MUX_B
ENTER = Confirm : CLEAR = Cancel
To delete a profile:
1. Select the Delete option from the Profiles sub-menu. The following screen is displayed.
Deleting Profile: MUX_B
ENTER = Confirm : CLEAR = Cancel
3-6 SBM75e Series Modulator Installation and Operation Manual
