Chapter 1
General Information
◼ Expansion Slots:
1 x M.2 B key 3042, 3052, 3080 for iDoor (PCIe/USB2.0, RAID support w/
SSD)
1 x M.2 E key 2230 for Wi-Fi (PCIe/USB2.0)
1 x M.2 B key 3052 for 5G LTE (PCIe/USB3.2/USB2.0)
1 x SIM card slot
◼ I/O Ports:
1 x DisplayPort 1.4a (video output)
1 x Type C (USB 3.2 Gen 2, DP 1.4a, 5V w/ 3A max)
2 x USB 3.2 Gen 1
4 x USB 2.0
2 x RS-232/422/485
(Optional) 2 x 4Ω speaker for audio out
1.2.3 Certification and Environment
Certification
◼ BSMI
◼ CCC
◼ CE
◼ FCC Class A
◼ CB/UL
◼ IP66-rated front panel
Environment
◼ Operating Temperature:
-10~60 °C (14~140 °F) (i5 w/o air flow)
-20~60 °C (-4~140 °F) (i7 w/o air flow)
◼ Storage Temperature: -30 ~ 70 °C (-22 ~ 158 °F)
◼ Humidity: 95% RH @ 40 °C, non-condensing
◼ Vibration Protection: 1 Grms random vibration (5 ~ 500 Hz) during opera-
tion (with SSD)
1.2.4 Power
◼ Input Voltage: 19 – 24V
DC
± 15%
◼ Power Consumption: Typ. 29W; Max. 65W
