Advantech TPC-B520 Series - Installation of Speaker Module

TPC-B520 User Manual
23
Chapter
2
System
Setup
2.5.3 Installation of Speaker Module
1. Remove the expansion cover.
2. Retrieve the cover plate from the speaker kit.
3. Install the speakers onto the cover.
NOTE!
A speaker expansion kit (98R1B520001) is required for speaker
installation.
4. Attach the cover to the chassis using the previously removed screw.
