A.1 Jumper and Connector Location
A.1.1 Board Layout
Figure A.1 Board Layout - Top View
Figure A.2 Board Layout - Bottom View
Table A.1: Board Placement
Place
Function
JCMOS1
Clear CMOS jumper
PSON1
AT/ATX jumper
P68, P22, P20, P38
5G module jumper
REMOTE1
Remote button connector
