Advantech TPC-B520 Series - M.2 B-Key Connector (M2 B1)

TPC-B520 User Manual
57
Appendix A
Connectors
40
NC
41
PERp0
38
NC
39
GND
36
NC
37
PETn0
34
NC
35
PETp0
32
NC
33
GND
22
NC
23
NC
20
NC
21
NC
18
GND
19
NC
16
NC
17
NC
14
NC
15
NC
12
NC
13
NC
10
NC
11
NC
8
NC
9
NC
6
NC
7
GND
4
3.3V
5
USB_D-
2
3.3V
3
USB_D+
1
GND
A.3.12 M.2 B-Key Connector (M2B1)
Table A.16: M.2 B-Key Connector (M2B1)
Pin
Signal
Pin
Signal
74
3.3V
75
CONFIG_2
72
3.3V
73
GND
70
3.3V
71
GND
68
NC
69
CONFIG_1
66
NC
67
RESET#
64
NC
65
NC
62
NC
63
NC
60
NC
61
NC
58
NC
59
NC
56
NC
57
GND
54
PEWAKE0#
55
REFCLKp
