2.5.2 Installation of 2.5" SATA SSD
1. Secure the SSD onto the bracket using four M3x4L screws.
2. Remove the expansion cover and flip it over.
3. Install the SSD and its bracket onto the expansion cover removed in the previous
step.
4. Attach the cover to the chassis using the previously removed screw.
0.
NOTE!
A SATA expansion kit (98R1B520000) is required for 2.5" SATA
SSD installation.
