Advantech TPC-B520 Series - Page 18

6
TPC-B520 User Manual
Table 1.2: Specifications
Part Number for
Cost Effective Version
FPM-D15W-
FCE
FPM-D18W-
FCE
FPM-D21W-
CE
FPM-D24W-
CE
LCD Panel
Display Size
15.6"
18"
21.5"
23.8"
Display Type
FHD TFT LED
LCD
FHD TFT LED
LCD
FHD TFT LED
LCD
FHD TFT LED
LCD
Aspect Ratio
16:9
Max. Resolution
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
Max. Color
16.7M
16.7M
16.7M
16.7M
Luminance
450 cd/m²
350 cd/m²
250 cd/m²
350 cd/m²
Viewing Angle
(H/V)
170°/170
178°/178°
178°/178°
178°/178°
Backlight Life
50,000 hr
50,000 hr
50,000 hr
30,000hr
Contrast Ratio
800:1
1000:1
1000:1
1000:1
Touchscreen
Type
PCAP
PCAP
PCAP
PCAP
Light Transmis-
sion
Above 88%
Above 85%
Above 88%
90%±3%
Anti-Glare
Treatment
Yes
Yes
Yes
Yes
Built-In iKey
N/A
N/A
N/A
N/A
Expandability
NFC Support on
Front Panel
N/A
N/A
N/A
N/A
Environment
Operating
Temperature
-20~60 °C
(-4~140 °F)
-20~60 °C
(-4~140 °F)
0~55 °C
(32~131 °F)
0~55 °C
(32~131 °F)
Storage
Temperature
-20~60 °C
(-4~140 °F)
-20~60 °C
(-4~140 °F)
-20~60 °C
(-4~140 °F)
-20~60 °C
(-4~140 °F)
Ingress Protection
Font IP66
Font IP66
Font IP66
Font IP66
Housing Color
Panel Frame and
Back Cover
Pantone 432C
Pantone 432C
Pantone 432C
Pantone 432C
