Advantech TPC-B520 Series - Page 71

TPC-B520 User Manual
59
Appendix A
Connectors
62
NC
63
NC
60
NC
61
NC
58
NC
59
NC
56
NC
57
GND
54
PEWAKE0#
55
REFCLKp
52
CLKREQ0#
53
REFCLKn
50
PERST0#
51
GND
48
NC
49
PETp0
46
NC
47
PETn0
44
NC
45
GND
42
NC
43
PERp0
40
NC
41
PERn0
38
NC
39
GND
36
NC
37
PETp1
34
NC
35
PETn1
32
NC
33
GND
30
NC
31
PERp1
28
NC
29
PERn1
26
NC
27
GND
24
NC
25
NC
22
NC
23
NC
20
NC
21
NC
10
3.3V
11
GND
8
NC
9
USB_D-
6
FULL_CARD_POW-ER_OFF#
7
USB_D+
4
3.3V
5
GND
2
3.3V
3
GND
1
NC
