AEM Performance Electronics CD-7 - Optional Momentary Button Kit; Description; Features

19
Optional Momentary Button Kit
Description
AEM kit part number 30-3610 - Panel mount momentary push buttons. Each kit includes 2 buttons, serrated lock
washers and nuts. Buttons are sealed with flying leads.
Note: a 35/64” drill bit may be used.
Features
· IP68 rated
· Normally open
· Flying leads, 20”
Kit Contents
· 1x Blue Button with o-ring, lock washer and nut
· 1x Yellow Button with o-ring, lock washer and
nut
· User Instructions
Specifications
· Current rating: 200mA (DC)
· Electrical Life: 500,000 cycles
· Mechanical Life: 1,000,000 Cycles
· Ingress protection: IP68 – Dust Tight,
Waterproof
· Mounting type: Panel Mount, Circular,
13.60mm Diam Cutout
· Operating Temperature: -30 to 85 deg C
· Voltage Rating: 50V (DC)
